RFID Paper Ticket
- PRODUCT DETAIL
Specification
|
Ticket Category
|
Conjoined type / Fan-fold form / Leaflet / Roll form |
|---|---|
|
Ticket Size
|
85.5* 54mm / 208*80mm or customized |
|
Ticket Thickness
|
0.20 mm~0.45mm (thickness can be customized) |
|
Material
|
coated paper / thermal paper / PET / PVC |
|
Inlay Material
|
PET + AL |
|
Standard Protocol
|
ISO 14443A / ISO 15693 / EPC CLASS1 GEN2 / ISO 18000-6C |
|
Packaging Chip
|
Packing high-frequency chip: Ultralight / Ultralight C / MIFARE Classic® 1K / MIFARE Classic® 4K / Ntag213 / Ntag215 / Ntag216 / ICODE SLI / ICODE SLIX Packing Ultra-high -frequency chip: Alien H3 / Alien H4 / Impinj M4 / Impinj M5 / UCODE G2XM / G2XL |
|
Operating Frequency
|
13.56MHz / 860-960MHz |
|
Operating Temperature
|
-30℃ to +50℃ |
|
Storage Temperature
|
-40℃~+100℃ |
|
Erasing Times
|
≥ 100,000 times |
|
Data Retention Period
|
≥ 10 years |
|
Packing
|
Continuous rolls or fan folded. |
|
Product Description
|
RFID conjoined tickets punched out of easy tear lines, it can be packed as a continuous roll packing or folded packing. |
|
Subsequent Process
|
Ticket surface can offset or silk screen printing contents, cover film/overlay and UV printing effects etc. Also it can do some special options, such as hot stamping hologram, inkjet serial number, barcode, QR code, ticket price, area code, seat number, time and other variable data. |
|
Application
|
Concert, PARTY, train tickets, bus tickets, tourist attractions, sports stadiums, conference venues, cinemas, theaters, large exhibitions, etc. |
Product Description
RFID paper ticket is a kind of new and environmentally friendly card, and they are now gradually replacing PVC cards. RFID paper tickets card are mainly used in consumption and entertainment fields like Mass transportation, Concert, Party, tourist attractions, sports stadiums, conference venues, cinemas, large exhibitions, etc
The low cost of materials (paper instead of PVC) substantially decreases their unit costs while maintaining all the advantages of RFID technology: rapid, practical and secure contactless data transfers
